| Model: | XY-L600 |
| Power supply: | 3-phase AC 380V/50HZ |
| Applicable bottle type: | Cans, glass bottles, PET bottles and cartons |
| Applicable bottle type range: | (1) Glass bottles, PET bottles, cans, etc., ranging from Ø55 to 110mm (2) Bottle height H80~320mm (Note: The diameter and height of each bottle type have a plus or minus error of 2 mm, otherwise it will be calculated as another bottle type) |
| Maximum power consumption: | 28KW |
| Working air pressure: | 0.6Mpa |
| Matching air compressor requirements: | Exhaust pressure: 0.8Mpa, flow: 0.25m³/min |
| Heat shrink film: | Thickness: 0.06 ~ 0.15mm (PE White film) |
| Width of packaging film: | ≤600mm |
| Feed conveyor belt level: | 950±50mm |
| Feed conveyor belt length: | Bottle feeding belt length 5000mm, network chain width 600mm |
| Equipment dimensions: | 9530×1080×1980 (mm) |
| Total weight of equipment: | 2000kg |
| Maximum package size: | L390×W280×320 (H) mm |
| Heat sealing knife length: | 630mm |
| Shrinkage temperature: | 130-260 ℃ |
| Contraction time: | 0-6S |
| Heat sealing temperature: | 150-260 ℃ |
| Maximum production speed: | 10-15 packs/min (depending on the actual packaging) |
| Noise: | ≤ 65 dB |
| Packaging form: | Cuff |
| Membrane packaging method: | The long side runs forward |
